Clinical NLP · Information Retrieval

Blood Report Analyzer and Recommendation Engine

A course prototype for extracting biomarkers from blood reports. I built the extraction, NER, retrieval, and training stages.

Context
AAI 6620 NLP final project · team with Om Patel and Yash Jain
Stack
PubMedBERT, PyMuPDF, FastAPI, FAISS, TF-IDF, SLURM

How it works

Explainer animation

Explainer animation, not a screen recording. From a blood report to biomarkers and recommendations, with the F1 qualifier kept in view.

Team project with Om Patel and Yash Jain.

  1. Document extraction

    Document extraction via PyMuPDF with an OCR fallback behind a router

  2. Biomedical NER

    Fine-tuned PubMedBERT for biomedical NER (biomarker, value, unit, reference-range). Chunked inference with overlap and span aggregation

  3. Measured on synthetic data

    Entity-token F1 0.8902 ± 0.0034 over 5-fold cross-validation, measured on synthetic, OCR-noise-augmented data rather than on clinical documents

  4. Hybrid retrieval

    Hybrid recommendation retrieval designed as TF-IDF plus MiniLM/FAISS semantic search with 0.6/0.4 score fusion; the recorded run fell back to the lexical branch over an 8-document corpus

Highlights

  • Fine-tuned PubMedBERT for biomedical NER (biomarker, value, unit, reference-range) at entity-token F1 0.8902 +/- 0.0034 over 5-fold cross-validation, measured on synthetic, OCR-noise-augmented data rather than on clinical documents
  • Chunked inference with overlap and span aggregation, token accuracy 0.923, precision 0.956 and recall 0.833
  • Document extraction via PyMuPDF with an OCR fallback behind a router
  • Hybrid recommendation retrieval designed as TF-IDF plus MiniLM/FAISS semantic search with 0.6/0.4 score fusion; the recorded run fell back to the lexical branch over an 8-document corpus
  • NER training on Northeastern's Explorer cluster (SLURM, NVIDIA H200)

How it was built

Our course pipeline reads a blood-report PDF or image. My share covered extraction, entity recognition, retrieval and training. A router picks PyMuPDF text extraction or an OCR fallback. I fine-tuned a PubMedBERT token classifier to tag biomarker, value, unit and reference range, using synthetic training reports with OCR-style noise, on Explorer H200 GPUs. Five-fold cross-validation gave entity-token F1 of 0.8902 +/- 0.0034 on that synthetic data. I also built hybrid retrieval for recommendations; teammates built interpretation, templating, the API and the interface. Limits: no clinical documents; the recorded retrieval run used only the lexical branch over eight documents.
